AR12TYGCGWKNTC
775,000 MMK
AR12TYGCGWKNTC
  • AR12TYGCGWKNTC
Payment Methods
AR12TYGCGWKNTC
775,000 MMK

AR12TYGCGWKNTC

  • Wind-Free Cooling
  • AI Auto Cooling
  • Wind-Free Good Sleep
  • Details
  • Specifications
  • Related
  • Reviews
  • Wind-Free Cooling
  • AI Auto Cooling
  • Wind-Free Good Sleep

Capacity

  • Capacity (Cooling, Btu/hr)Capacity (Cooling, Btu/hr)
    •
  • Capacity (Heating, Btu/hr)Capacity (Heating, Btu/hr)
    •
  • Capacity (Cooling, Min - Max, Btu/hr)Capacity (Cooling, Min - Max, Btu/hr)
    •
  • Capacity (Heating, Min - Max, Btu/hr)Capacity (Heating, Min - Max, Btu/hr)
    •
  • Capacity (Cooling, kW)Capacity (Cooling, kW)
    •
  • Capacity (Heating, kW)Capacity (Heating, kW)
    •
  • Capacity (Cooling, Min - Max, kW)Capacity (Cooling, Min - Max, kW)
    •
  • Capacity (Heating, Min - Max, kW)Capacity (Heating, Min - Max, kW)
    •
  • Capacity (Cooling, Kcal/hr)Capacity (Cooling, Kcal/hr)
    •
  • Capacity (Heating, Kcal/hr)Capacity (Heating, Kcal/hr)
    •
  • Capacity (Cooling, kJ/h)12660 kJ/hW
    •
  • Capacity (Heating, kJ/h)Capacity (Heating, kJ/h)
    •
  • Capacity (Cooling, Min - Max, kJ/h)5,000 ~ 14,000 kJ/hW
    •
  • Capacity (Heating, Min - Max, kJ/h)Capacity (Heating, Min - Max, kJ/h)

Energy Efficiency

  • SEER(W/W, Energy Label)SEER(W/W, Energy Label)
    •
  • SCOP(W/W, Energy Label)SCOP(W/W, Energy Label)
    •
  • SEER(Btu/hW)SEER(Btu/hW)
    •
  • SCOP(Btu/hW)SCOP(Btu/hW)
    •
  • HSPF(Btu/hW)HSPF(Btu/hW)
    •
  • AEER (W/W)AEER (W/W)
    •
  • ACOP (W/W)ACOP (W/W)
    •
  • ISEER (W/W)ISEER (W/W)
    •
  • EER (Cooling, W/W)EER (Cooling, W/W)
    •
  • COP (Heating, W/W)COP (Heating, W/W)
    •
  • EER (Cooling, Btu/hW)EER (Cooling, Btu/hW)
    •
  • COP (Heating, Btu/hW)COP (Heating, Btu/hW)
    •
  • EER (Cooling, kJ/hW)12.06 kJ/hW
    •
  • HSPFHSPF
    •
  • CSPFCSPF
    •
  • Pdesign(Cooling, kW)Pdesign(Cooling, kW)
    •
  • Annual electricity consumption (cooling, kWh/annum)Annual electricity consumption (cooling, kWh/annum)
    •
  • Energy Efficiency Class for heating in 'Warmer' heating season (Grade)Energy Efficiency Class for heating in 'Warmer' heating season (Grade)
    •
  • Energy Efficiency Class for heating in 'Warmer' heating season (W/W)Energy Efficiency Class for heating in 'Warmer' heating season (W/W)
    •
  • Pdesign(Heating, kW)Pdesign('Average' heating season, kW)
    •
  • Annual electricity consumption (heating, kWh/annum)Annual electricity consumption ('Average' heating season, kWh/annum)
    •
  • Energy Efficiency Class for heating in 'Colder' heating season (Grade)Energy Efficiency Class for heating in 'Colder' heating season (Grade)
    •
  • Energy Efficiency Class for heating in 'Colder' heating season (W/W)Energy Efficiency Class for heating in 'Colder' heating season (W/W)
    •
  • COP (Heating, Btu/W)COP (Heating, Btu/W)
    •
  • Energy Star Rating (Cooling)Energy Star Rating (Cooling)
    •
  • Energy Star Rating (Heating)Energy Star Rating (Heating)
    •
  • Energy Star CertificationEnergy Star Certification

Noise Level

  • Sound Power Level(Indoor, Cooling, dBA)Sound Power Level(Indoor, Cooling, dBA)
    •
  • Sound Power Level(Indoor, Heating, dBA)Sound Power Level(Indoor, Heating, dBA)
    •
  • Sound Power Level(Outdoor, Cooling, dBA)Sound Power Level(Outdoor, Cooling, dBA)
    •
  • Sound Power Level(Outdoor, Heating, dBA)Sound Power Level(Outdoor, Heating, dBA)
    •
  • Sound Pressure Level(Indoor,Cooling, Turbo/High/Mid/Low/Quiet, dBA)Sound Pressure Level(Indoor,Cooling, Turbo/High/Mid/Low/Quiet, dBA)
    •
  • Sound Pressure Level(Indoor,Heating, Turbo/High/Mid/Low/Quiet, dBA)Sound Pressure Level(Indoor,Heating, Turbo/High/Mid/Low/Quiet, dBA)
    •
  • Sound Pressure Level(Outdoor, Cooling, dBA)Sound Pressure Level(Outdoor, Cooling, dBA)
    •
  • Sound Pressure Level(Outdoor, Heating, dBA)Sound Pressure Level(Outdoor, Heating, dBA)
    •
  • Noise Level (Indoor, High/Low, dBA)37 / 22 dBA
    •
  • Noise Level (Indoor, High/Low/Silence, dBA)Noise Level (Indoor, High/Low/Silence, dBA)
    •
  • Noise Level (Outdoor, High/Low, dBA)48 dBA
    •
  • Noise Level (Outdoor, High/Low/Silence, dBA)Noise Level (Outdoor, High/Low/Silence, dBA)
    •
  • Sound Pressure (Indoor, High/Low, dBA)Sound Pressure (Indoor, High/Low, dBA)
    •
  • Sound Pressure (Outdoor, High/Low, dBA)Sound Pressure (Outdoor, High/Low, dBA)
    •
  • Sound Power (Indoor, High, dBA)Sound Power (Indoor, High, dBA)
    •
  • Sound Power (Outdoor, High, dBA)Sound Power (Outdoor, High, dBA)

Electrical Data

  • Power Source(Φ/V/Hz)1 / 220~240 / 60
    •
  • Power Consumption(Cooling, W)1050 W
    •
  • Power Consumption(Heating, W)Power Consumption(Heating, W)
    •
  • Operating Current(Cooling, A)7.0 A
    •
  • Operating Current(Heating, A)Operating Current(Heating, A)

Physical specification

  • Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)880*290*375 mm
    •
  • Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)844*622*353 mm
    •
  • Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)820*299*215 mm
    •
  • Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)720*548*265 mm
    •
  • Gross Weight (Indoor, kg)10.5 kg
    •
  • Gross Weight (Outdoor, kg)25.2 kg
    •
  • Net Weight (Indoor, kg)9.2 kg
    •
  • Net Weight (Outdoor, kg)23.2 kg
    •
  • Loading Quantity (20/40/40Hft without Pipe)96 / 197 / 232
    •
  • Loading Quantity (20/40/40Hft with Pipe)Loading Quantity (20/40/40Hft with Pipe)

Technical Information

  • Piping Length (Max, m)15 m
    •
  • Piping Height (Max, m)7 m
    •
  • SVC Valve (Liquid (ODxL))6.35
    •
  • SVC Valve (Gas (ODxL))9.52
    •
  • Moisture Removal (l/hr)1.5 l/hr
    •
  • Air Circulation (Cooling, ㎥/min)11.2 ㎥/min
    •
  • Refrigerant (Type)R32
    •
  • Refrigerant (Charging, g)Refrigerant (Charging, g)
    •
  • Refrigerant (Charging, kg)0.55 kg
    •
  • Refrigerant (Charging, tCO2e)Refrigerant (Charging, tCO2e)
    •
  • Low Ambient (Cooling, ℃)16~46 ℃
    •
  • Low Ambient (Heating, ℃)Low Ambient (Heating, ℃)
    •
  • Outdoor Unit (Compressor Type)BLDC
    •
  • PowerBoostPowerBoost
    •
  • 8-Pole Compressor8-Pole Compressor
    •
  • DuraFin™DuraFin™
    •
  • Outdoor Unit (Anti-Corrosion Fin)Yes
    •
  • Outdoor Unit (Multi-Channel Condensor)Outdoor Unit (Multi-Channel Condensor)
    •
  • Smart InverterSmart Inverter

Air Flow

  • Wide Twin BladeWide Twin Blade
    •
  • Optimal Single BladeOptimal Single Blade
    •
  • Air Direction Control (Up/Down)Auto
    •
  • Air Direction Control (Left/Right)Auto
    •
  • Air Flow Control Step (Cool/Fan)5/4
    •
  • Natural BreezeNatural Breeze

Air Purification

  • IonizerIonizer
    •
  • PM 2.5 FilterPM 2.5 Filter
    •
  • PM 1.0 FilterNo
    •
  • Laser PM SensorLaser PM Sensor
    •
  • Tri Care FilterYes
    •
  • Easy Filter Plus (Anti-Bacteria)Yes
    •
  • Neo Triple FilterNeo Triple Filter
    •
  • S-Plasma IonS-Plasma Ion
    •
  • Full HD FilterFull HD Filter
    •
  • Allergy CareAllergy Care
    •
  • Anti-BacteriaAnti-Bacteria
    •
  • Anti-VirusAnti-Virus
    •
  • Auto Clean (Self Cleaning)Yes
    •
  • Virus DoctorVirus Doctor
    •
  • Easy filterEasy filter
    •
  • Easy Filter PlusEasy Filter Plus

Convenience

  • Smart Home (Wi-Fi)Smart Home (Wi-Fi)
    •
  • Smart wifiSmart wifi
    •
  • SmartThingsNo
    •
  • AI Auto CoolingNo
    •
  • Motion Detect SensorNo
    •
  • Motion Sensor SaverMotion Sensor Saver
    •
  • Filter Cleaning IndicatiorYes
    •
  • Indoor Temp. DisplayYes
    •
  • Display On/OffYes
    •
  • Beep On/OffYes
    •
  • Real-Time TimerReal-Time Timer
    •
  • 24-Hour TimerYes
    •
  • Auto ChangeoverNo
    •
  • Auto RestartYes
    •
  • Auto GrilleAuto Grille
    •
  • DREDDRED

Operating Mode

  • 2 Step Cooling2 Step Cooling
    •
  • Auto ModeYes
    •
  • Fast CoolYes
    •
  • Comfort CoolComfort Cool
    •
  • Turbo ModeTurbo Mode
    •
  • Dlight CoolDlight Cool
    •
  • Good SleepYes
    •
  • Single User ModeSingle User Mode
    •
  • Eco ModeYes
    •
  • Smart SaverSmart Saver
    •
  • DehumidificationYes
    •
  • Fan ModeYes
    •
  • QuietYes
    •
  • Mood LightingMood Lighting

Smart

  • BluetoothBluetooth
    •
  • WiFi Dongle(Separate sale) SupportWiFi Dongle(Separate sale) Support
    •
  • WiFi KitWiFi Kit
    •
  • WiFi EmbeddedNo

App Connectivity

  • SmartThings App SupportNo
