AR24TYHYBWKNST
1,140,000 MMK
AR24TYHYBWKNST
  • AR24TYHYBWKNST
Payment Methods
AR24TYHYBWKNST
1,140,000 MMK

AR24TYHYBWKNST

  • AI Auto Cooling
  • Fast Cooling
  • SmartThings
  • Details
  • Specifications
  • Related
  • Reviews
  • AI Auto Cooling
  • Fast Cooling
  • SmartThings
  • Capacity
    • Capacity (Cooling, Btu/hr)21500 Btu/hr
    • Capacity (Cooling, Min - Max, Btu/hr)5,000 ~ 25,000 Btu/hr
    • Capacity (Cooling, kW)6.30 kW
    • Capacity (Cooling, Min - Max, kW)1.47 ~ 7.33 kW
  • Energy Efficiency
    • SEER(Btu/hW)18.00
    • EER (Cooling, W/W)3.41 W/W
    • EER (Cooling, Btu/hW)11.62 Btu/hW
    • Energy Efficiency Class for cooling (Grade)5
  • Noise Level
    • Noise Level (Indoor, High/Low, dBA)45 / 30 dBA
    • Noise Level (Outdoor, High/Low, dBA)52 dBA
  • Electrical Data
    • Power Source(Φ/V/Hz)1 / 220-240 / 50
    • Power Consumption(Cooling, W)1850 W
    • Operating Current(Cooling, A)8.5 A
  • Physical specification
    • Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)1115*290*375 mm
    • Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)1023*724*413 mm
    • Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)1055*299*215 mm
    • Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)880*638*310 mm
    • Gross Weight (Indoor, kg)13.1 kg
    • Gross Weight (Outdoor, kg)38.4 kg
    • Net Weight (Indoor, kg)11.5 kg
    • Net Weight (Outdoor, kg)35.4 kg
    • Loading Quantity (20/40/40Hft without Pipe)65 / 138 / 154
  • Technical Information
    • Piping Length (Max, m)30 m
    • Piping Height (Max, m)15 m
    • SVC Valve (Liquid (ODxL))6.35
    • SVC Valve (Gas (ODxL))15.88
    • Moisture Removal (l/hr)2.5 l/hr
    • Air Circulation (Cooling, ㎥/min)18.6 ㎥/min
    • Refrigerant (Type)R32
    • Refrigerant (Charging, kg)0.80 kg
    • Low Ambient (Cooling, ℃)16~46 ℃
    • Outdoor Unit (Compressor Type)BLDC
    • Outdoor Unit (Anti-Corrosion Fin)Yes
  • Air Flow
    • Air Direction Control (Up/Down)Auto
    • Air Direction Control (Left/Right)Manual
    • Air Flow Control Step (Cool/Fan)5/4
  • Air Purification
    • PM 1.0 FilterNo
    • Tri Care FilterNo
    • Easy Filter Plus (Anti-Bacteria)Yes
    • Auto Clean (Self Cleaning)Yes
  • Convenience
    • SmartThingsNo
    • AI Auto CoolingNo
    • Motion Detect SensorNo
    • Filter Cleaning IndicatiorYes
    • Indoor Temp. DisplayYes
    • Display On/OffYes
    • Beep On/OffYes
    • 24-Hour TimerYes
    • Auto ChangeoverNo
    • Auto RestartYes
  • Operating Mode
    • Auto ModeYes
    • Fast CoolYes
    • Good SleepYes
    • Eco ModeYes
    • DehumidificationYes
    • Fan ModeYes
    • QuietYes
  • Smart
    • WiFi EmbeddedNo
  • App Connectivity
    • SmartThings App SupportNo
